PEEK Material Temperature Range

Nov. 11, 2024

PEEK Material Temperature Range


Polyetheretherketone (PEEK) is a high-performance thermoplastic known for its exceptional thermal stability and mechanical properties across a wide temperature range.

Here are the key temperature characteristics of PEEK:



Temperature Ranges of PEEK



Glass Transition Temperature (Tg): PEEK has a Tg ranging from 143°C to 165°C (approximately 289°F to 329°F) depending on the specific grade of the material.



Melting Temperature (Tm): The melting point of PEEK is typically around 341°C to 343°C (about 646°F to 649°F) which allows it to be processed at high temperatures.



Continuous Use Temperature: PEEK can be used continuously at temperatures up to 260°C (about 500°F) without significant degradation of its mechanical properties.



Short-term Use Temperature: It can withstand short-term exposure to temperatures as high as 300°C (approximately 572°F) for limited periods.



Low-Temperature Performance: PEEK maintains satisfactory performance at low temperatures, functioning effectively down to -50°C (-58°F) and, for brief durations, even down to -100°C (-148°F) without losing its structural integrity.




Summary of Key Properties



PropertyValue
Glass Transition Temperature143°C - 165°C
Melting Temperature341°C - 343°C
Continuous Use TemperatureUp to 260°C
Short-term Use TemperatureUp to 300°C
Low-Temperature PerformanceDown to -50°C (-100°C for brief periods)



PEEK's ability to perform under such diverse temperature conditions makes it suitable for applications in various industries, including aerospace, automotive, medical, and electronics, where both high thermal resistance and mechanical strength are critical.
