PEEK Pipe




  • PEEK Tubing 1/16" x 0.25mm
  • PEEK Tubing 1/16" x 0.25mm
  • PEEK Tubing 1/16" x 0.25mm
  • PEEK Tubing 1/16" x 0.25mm

PEEK Tubing 1/16" x 0.25mm

1/16 Inch Bending PEEK Tubing

ARKPEEK-1000 PEEK Tubing (1/16" x 0.75mm) is engineered for precision HPLC and UHPLC systems, delivering ultra-low bleed, exceptional chemical resistance, and stability at pressures exceeding 10,000 psi. Ideal for gradient elution, mass spectrometry, and lab analytics, its inert surface minimizes contamination. FDA-compliant, USP Class VI-certified, and compatible with aggressive solvents. Trust ARKPEEK-1000 for reproducible results in critical chromatography workflows.

PEEK Tubing Chemical Compatibility


MATERIAL GRADE

PEEK Tubing 1/16" x 0.25mm


_______________________________________________________________________________________________________________________________________________________________________


ARKPEEK-1000 PEEK Tubing 1/16" x 0.75mm – The Gold Standard for HPLC & Analytical Chromatography


Meet ARKPEEK-1000, the advanced PEEK tubing specifically engineered to meet the rigorous demands of High-Performance Liquid Chromatography (HPLC), UHPLC, and analytical lab systems. With a precision-engineered 1/16" outer diameter and 0.75mm wall thickness, this tubing combines unmatched mechanical robustness, ultra-low extractables, and exceptional chemical inertness to ensure peak performance in the most sensitive analytical workflows.


Why ARKPEEK-1000 Excels in HPLC Applications

Ultra-Low Bleed & Contamination Resistance: ARKPEEK-1000’s optimized polymer formulation minimizes leachables and extractables, even under high-pressure gradients (10,000+ psi), ensuring baseline stability and accurate peak resolution for mass spectrometry (MS) and UV/VIS detection.


High-Pressure Resilience: Reinforced molecular structure withstands extreme pressure cycling, making it ideal for UHPLC systems, preparative chromatography, and automated lab equipment.

Broad Chemical Compatibility: Resists hydrolysis, acids, bases, and aggressive solvents (e.g., acetonitrile, TFA, DMSO), ensuring longevity in reversed-phase, ion-exchange, and size-exclusion chromatography.

Smooth Bore Design: Precision-machined inner surface reduces turbulence and carryover, critical for maintaining reproducibility in multi-sample analyses.

Certified for Critical Environments:
ARKPEEK-1000 is USP Class VI-certified and FDA-compliant, meeting strict biocompatibility standards for pharmaceutical QC, clinical diagnostics, and biopharma research. Its ISO 9001-certified manufacturing guarantees consistent dimensional tolerances (±0.02mm) and traceability for regulated industries.


Key Features & Technical Advantages

Temperature Stability: Operates seamlessly from -70°C to 260°C, suitable for high-temperature HPLC columns and cryogenic applications.

Non-Conductive & Non-Magnetic: Perfect for LC-MS systems and environments sensitive to electrical interference.

Abrasion Resistance: Withstands repeated connections/disconnections in autosamplers, injection valves, and column fittings.

Customizable: Available in pre-cut lengths, coiled configurations, or bulk spools for OEM integration.


Applications Beyond HPLC

Biopharmaceutical: Sterilizable tubing for buffer preparation, bioprocessing, and vaccine production.

Environmental Testing: Reliable fluid transfer for PFAS analysis, pesticide detection, and water quality monitoring.

Food & Beverage: Safe for solvent-based extraction and contaminant testing in FDA-regulated labs.

Research & Academia: Low-dead-volume connections for nanoflow chromatography and microfluidic devices.


Why Choose ARKPEEK-1000?

Zero Particulate Generation: Cleanroom-packaged to meet ISO Class 5 standards for sensitive applications.

Global Compliance: REACH, RoHS, and EP 3.1.3 compliant for international markets.

Technical Support: Access to HPLC application guides, chemical compatibility charts, and pressure-rating data.


_______________________________________________________________________________________________________________________________________________________________________


PEEK Tubing Size HPLC

Product specifications
NameODID
PEEK Capillary1(±0.05)0.45(±0.05)
1/16"PEEK CapillaryΦ1.5-Φ1.60Φ0.13
1/16"PEEK CapillaryΦ1.5-Φ1.60Φ0.25
1/16"PEEK CapillaryΦ1.5-Φ1.60Φ0.50
1/16"PEEK CapillaryΦ1.5-Φ1.60Φ0.75
1/16"PEEK CapillaryΦ1.5-Φ1.60Φ1.25
PEEK CapillaryΦ1.7-Φ1.8Φ0.66-Φ0.8
PEEK CapillaryΦ2.5Φ1.5
PEEK CapillaryΦ2.5Φ1.9
PEEK CapillaryΦ2.45Φ2.1
1/8"PEEK CapillaryΦ3.10-Φ3.22Φ1.00
1/8"PEEK CapillaryΦ3.10-Φ3.22Φ1.60
PEEK CapillaryΦ4Φ3.4
PEEK CapillaryΦ4.5Φ2.5
PEEK CapillaryΦ20.5Φ16.5
PEEK CapillaryΦ12Φ11
PEEK CapillaryΦ11Φ7.5
PEEK CapillaryΦ6Φ4
PEEK CapillaryΦ19.8Φ16.5
