PEEK Tubing 1/16" x 0.38mm

1/16" PEEK Tubing in Laboratory

Our 1/16" x 0.38mm PEEK tubing delivers unmatched precision for high-pressure and micro-scale applications. Engineered with an ultra-thin wall for minimal dead volume, it excels in HPLC, UHPLC, and microfluidic systems. Resists 15,000+ psi, aggressive solvents, and extreme temperatures (up to 260°C). FDA-compliant and USP Class VI-certified for biopharmaceutical and analytical workflows. Ideal for lab-on-a-chip, nanoscale research, and precision fluid delivery.


MATERIAL GRADE

PEEK Tubing 1/16" x 0.38mm


_______________________________________________________________________________________________________________________________________________________________________


PEEK Tubing 1/16" x 0.38mm – Precision Engineered for Micro-Scale & High-Pressure Applications

Introducing our ultra-thin PEEK tubing (1/16" OD x 0.38mm wall thickness), designed to meet the rigorous demands of modern analytical laboratories, microfluidics, and high-pressure chromatography. With its microbore design and exceptional mechanical properties, this tubing is the ideal solution for applications requiring minimal dead volume, ultra-low bleed, and resistance to extreme operational conditions.


Key Advantages for Critical Workflows

Ultra-Thin Wall Precision: The 0.38mm wall thickness ensures reduced dead volume and enhanced flow dynamics, critical for microfluidic devices, nano-LC systems, and lab-on-a-chip technologies.

High-Pressure Resilience: Rated for 15,000+ psi, this tubing maintains structural integrity under extreme pressure cycling, making it ideal for UHPLC, preparative chromatography, and automated high-throughput screening.

Chemical Inertness: Resists hydrolysis, acids, bases, and aggressive solvents (e.g., acetonitrile, TFA, DCM), ensuring compatibility with reversed-phase, ion-exchange, and size-exclusion chromatography.

Temperature Stability: Operates seamlessly from -50°C to 260°C, suitable for cryogenic sample handling and high-temperature sterilization (autoclave, gamma radiation).


Certified for Regulated Industries

USP Class VI & FDA Compliance: Meets stringent biocompatibility standards for pharmaceutical QC, clinical diagnostics, and implantable medical devices.

ISO 9001-Certified Manufacturing: Guarantees dimensional tolerances of ±0.015mm and traceability for regulated environments like biopharma and semiconductor manufacturing.


Applications Across Industries

Analytical Chemistry: Precision fluid transfer in HPLC, LC-MS, and capillary electrophoresis systems.

Biotechnology: Sterilizable tubing for single-use bioreactors, cell culture media delivery, and vaccine production.

Microfluidics & Lab-on-a-Chip: Low-dead-volume connections for organ-on-chip models, point-of-care diagnostics, and synthetic biology.

Nanotechnology: Reliable performance in nanoparticle synthesis and nanoscale fluidic control.


Customization & Technical Support

Tailored Solutions: Available in pre-cut lengths, spooled configurations, or coiled formats for OEM integration.

Surface Finish Options: Electropolished inner bore for reduced protein adsorption and carryover in sensitive assays.

Technical Resources: Access to pressure-rating charts, chemical compatibility guides, and application-specific prototyping support.


Why Choose Our 0.38mm PEEK Tubing?

Zero Extractables: Cleanroom-packaged to ISO Class 4 standards for particle-sensitive workflows.

Global Compliance: REACH, RoHS, and EP 3.1.3 certified for international markets.

Durability: Superior abrasion resistance for repeated use in autosamplers, injection valves, and high-cycle systems.


_______________________________________________________________________________________________________________________________________________________________________


PEEK Tubing Guide

Product specifications
NameODID
PEEK Capillary1(±0.05)0.45(±0.05)
1/16"PEEK CapillaryΦ1.5-Φ1.60Φ0.13
1/16"PEEK CapillaryΦ1.5-Φ1.60Φ0.25
1/16"PEEK CapillaryΦ1.5-Φ1.60Φ0.50
1/16"PEEK CapillaryΦ1.5-Φ1.60Φ0.75
1/16"PEEK CapillaryΦ1.5-Φ1.60Φ1.25
PEEK CapillaryΦ1.7-Φ1.8Φ0.66-Φ0.8
PEEK CapillaryΦ2.5Φ1.5
PEEK CapillaryΦ2.5Φ1.9
PEEK CapillaryΦ2.45Φ2.1
1/8"PEEK CapillaryΦ3.10-Φ3.22Φ1.00
1/8"PEEK CapillaryΦ3.10-Φ3.22Φ1.60
PEEK CapillaryΦ4Φ3.4
PEEK CapillaryΦ4.5Φ2.5
PEEK CapillaryΦ20.5Φ16.5
PEEK CapillaryΦ12Φ11
PEEK CapillaryΦ11Φ7.5
PEEK CapillaryΦ6Φ4
PEEK CapillaryΦ19.8Φ16.5
