PEEK Sheet Customized
Elevate your projects with our meticulously crafted PEEK round sheets, meticulously engineered to deliver exceptional performance. These circular sheets boast superior durability and precision, offering a reliable solution across diverse applications. Crafted from high-quality PEEK material, known for its resilience and chemical resistance, these thin yet robust sheets are customizable to fit your specific requirements. Whether for precision engineering, manufacturing, or specialized applications, our PEEK circular sheets stand as a testament to quality and reliability, ensuring consistent performance and longevity.
_______________________________________________________________________________________________________________________________________________________________________
PEEK round sheets are an excellent choice for industries requiring high-performance thermoplastics. With exceptional mechanical strength, wear resistance, and chemical stability, these sheets perform reliably under extreme conditions. We provide thermoplastic PEEK sheets in various sizes, with custom cutting options to match your specific application needs. Whether you need a pure PEEK sheet at an affordable price or a precision-cut round PEEK sheet, we offer cost-effective solutions with superior quality.
Our thermoplastic PEEK sheets for sale are widely used in aerospace, medical, semiconductor, and industrial applications due to their high-temperature resistance and low friction properties. Looking for a PEEK sheet round cut or custom-cut PEEK sheet? We ensure precise cutting with minimal waste, helping you reduce costs while optimizing material usage. Contact us today for pure PEEK sheet pricing and customized solutions!
_______________________________________________________________________________________________________________________________________________________________________
ARKPEEK Materials
ARKPEEK-1000: 100% PEEK
Produced from virgin polyetheretherketone resin and offers the highest toughness and impact resistance of all types.
ARKPEEK-CF30: 30% Carbon Fiber + 70% PEEK
Carbon fiber reinforcement lends the material a high level of rigidity and creep strength, high mechanical strength and heat conductivity values.
ARKPEEK-GF30: 30% Glass Fiber + 70% PEEK
Glass filled PEEK exhibits increased mechanical strength and high rigidity. Improved creep strength and dimensional stability are achieved by this glass filled PEEK. These properties make this material suitable for use in parts which are exposed to high static loads over long periods in high temperature conditions.
ARKPEEK-MOD: 10% Carbon Fiber + 10% PTFE +10% Graphite + 70% PEEK
High performance engineering plastic with product characteristics including excellent sliding and abrasion & wear resistance, high mechanical strength and high dimensional stability. The long term service temperature range is from -70°C to 260°C and has a short term maximum service temperature of 310°C.
_______________________________________________________________________________________________________________________________________________________________________
PEEK Sheet Dimensions Chart
NO. | Dimension (mm) | Weight ( g ) |
1 | 0.5*700*1000 | 480 |
2 | 1*700*1000 | 950 |
3 | 2*700*1000 | 1900 |
4 | 3*700*1000 | 2800 |
5 | 4*650*1000 | 3400 |
6 | 5*650*1000 | 4300 |
7 | 67×31×1000 | 2700 |
8 | 80x15x1000 | 1560 |
9 | 100x25x1000 | 3100 |
10 | 120x38x1000 | 5500 |
11 | 195×33×1000 | 8365 |
12 | 175x162×1000 | 36855 |
13 | 395x12.5x1000 | 6419 |
14 | 422x15x1000 | 8229 |
15 | 422x66x1000 | 36207 |
16 | Insulation block (with Utype)280x45x1000 | 15000 |
17 | 600×6x1000 | 4680 |
18 | 600x8×1000 | 6240 |
19 | 600×9×1000 | 7020 |
20 | 600x15x1000 | 11700 |
21 | 600×20x1000 | 15600 |
22 | 600×25×1000 | 19500 |
23 | 600x30x1000 | 23400 |
24 | 600x35×1000 | 27300 |
25 | 600×40×1000 | 31200 |
26 | 600x45x1000 | 35100 |
27 | 600x50×1000 | 39000 |
28 | 600x60x1000 | 46800 |
29 | 800x20x1000 | 20800 |
30 | 800x30x1000 | 31200 |
